Rockhopper Sport
Rockhopper Sport
SKU: 91824-6404
Low stock: 1 left
Read More
Read More
All barn-burner and no benchwarmer, the Rockhopper Sport throws out the playbook when it comes to putting performance points on the board while playing some serious defense on behalf of your wallet.
Game-ready with Tektro M275 hydraulic disc brakes, Shimano CUES shifting, and an SR SunTour XCM fork that’s built to hustle, the Rockhopper Sport can tack up the win on any given Sunday—and the rest of the week too for that matter.
- A heart of gold, presented in our lightweight yet durable Premium A1 Aluminum, the Rockhopper’s butted aluminum frame features hydroformed top and downtubes to keep weight low and strength high, all while providing increased standover clearance, slick internal cable routing, and dropper-post compatibility.
- A heart of gold, presented in our lightweight yet durable Premium A1 Aluminum, the Rockhopper’s butted aluminum frame features hydroformed top and downtubes to keep weight low and strength high, all while providing increased standover clearance, slick internal cable routing, and dropper-post compatibility.
- To ensure that the Rockhopper offers both the best fit and best performance for every person, no matter their measure, we’ve paired each Rockhopper frame size with the optimal wheel size. The result is a Rockhopper to fit every rider and the assurance that every Rockhopper is rolling on the best-handling wheel for its frame size.
- Bringing our Rx Tune to Rockhopper for the very first time, the lockout-equipped SR Suntour XCM with custom Multi-Circuit damping brings size-specific travel and spring rates to the show in a performance that’s sure to impress while also ensuring consistent geometry, handling, and suspension performance, regardless of frame or wheel size.
- Beautifully beastly, Tektro hydraulic disc brakes pack a mean bite but deliver their power with a refined, intuitive feel to make for a package that punches way above its pay grade.
- Keep things simple with a durable 1x Shimano drivetrain with plenty of range and a clutch-equipped rear derailleur that keeps your ride quiet—and your chain on.
- Pair dead-reliable hubs from Formula with our 25-millimeter internal diameter, hookless Specialized rims for a strong, light, and durable wheelset hat trick.
Share
Technical Specifications
Frameset
Frame
Specialized A1 premium butted alloy, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger, stealth rack mounts, dropper post compatible
Seat Binder
Alloy, quick release, 34.9
Suspension
Fork
SR Suntour XCM 29, 30mm stanchions, Rx Tune, coil spring, QR, 90/100mm travel (size-specific), 42mm offset
Cockpit
SeatPost
Alloy, 2-bolt clamp, 30.9mm
Stem
3D-forged alloy, 31.8mm, 7-degree rise
Handlebars
Stout Mini Rise, alloy, 9-degree backsweep, 15mm rise, 31.8mm
Saddle
Bridge Sport, Steel rails, 155/143mm
Grips
Specialized Trail Grips, lock-on
Brakes
Front Brake
Tektro BR-M275 Hydraulic Disc, 180/160mm
Rear Brake
Tektro BR-M275 Hydraulic Disc, 160mm
Drivetrain
Rear Derailleur
SHIMANO REAR DERAILLEUR, RD-U4000, CUES, GS 9-SPEED, TOP NORMAL, SHADOW DESIGN
Shift Levers
Shimano CUES SL-U4000-9R,RAPIDFIRE PLUS
Cassette
SHIMANO CUES CS-LG300-9, 9-SPEED, 11-41T
Chain
SHIMANO CN-LG500, W/QUICK-LINK
Crankset
Stout 1x, forged alloy
Bottom Bracket
Square-tapered, 73mm, internal bearings, 122.5mm spindle
Wheels & Tires
Rims
Specialized alloy, disc only, double-wall, 25mm inner width, 32h
Front Hub
Formula SP-2120 6-Bolt, disc, 100x9mm spacing, quick-release
Rear Hub
Formula SP-2125, 6-Bolt freehub, disc, 135x9mm spacing, quick-release
Spokes
Stainless, 14g
Front Tire
Fast Trak Sport, 650b/29x2.35"
Rear Tire
Fast Trak Sport, 650b/29x2.35"
Inner Tubes
Standard 40mm SV 650B/29x1.75-2.4
Weight
Weight
13.38 kg (29 lb, 8.0 oz)
Weight Size
MD
Geometry
S - 27.5 | M - 27.5 | S - 29 | M - 29 | L - 29 | XL - 29 | XXL - 29 | |
---|---|---|---|---|---|---|---|
Crank Length | 165mm | 170mm | 170mm | 170mm | 170mm | 175mm | 175mm |
Handlebar Width | 700mm | 720mm | 740mm | 720mm | 740mm | 740mm | 740mm |
Stem Length | 40mm | 40mm | 60mm | 40mm | 60mm | 60mm | 70mm |
Saddle Width | 155mm | 155mm | 143mm | 155mm | 143mm | 143mm | 143mm |
Seatpost Length | 300mm | 350mm | 400mm | 350mm | 400mm | 400mm | 400mm |
Crank Length | 160mm | 165mm | 165mm | 170mm | 170mm | 170mm | 175mm |
Handlebar Width | 700mm | 700mm | 720mm | 720mm | 740mm | 740mm | 740mm |
Saddle Width | 143mm | 155mm | 155mm | 155mm | 143mm | 143mm | 143mm |
Wheel Size | 26in | 27.5in | 27.5in | 29in | 27.5in | 29in | 29in |
Stack | 543mm | 559mm | 573mm | 607mm | 589mm | 616mm | 626mm |
Reach | 355mm | 375mm | 395mm | 405mm | 415mm | 425mm | 445mm |
Head-Tube Length | 95mm | 95mm | 100mm | 95mm | 105mm | 95mm | 105mm |
Head-Tube Angle | 68° | 68° | 68° | 68.5° | 68° | 68.5° | 68.5° |
B-B Height | 295mm | 310mm | 310mm | 310mm | 310mm | 310mm | 310mm |
B-B Drop | 44mm | 43mm | 43mm | 62mm | 43mm | 62mm | 62mm |
Trail | 94mm | 97mm | 97mm | 97mm | 97mm | 97mm | 97mm |
Fork Length (full) | 455mm | 475mm | 485mm | 505mm | 495mm | 515mm | 515mm |
Fork Rake/Offset | 40mm | 42mm | 42mm | 46mm | 42mm | 46mm | 46mm |
Front-Center | 601mm | 630mm | 656mm | 672mm | 682mm | 696mm | 719mm |
Chain-Stay Length | 420mm | 440mm | 440mm | 440mm | 440mm | 440mm | 440mm |
Wheelbase | 1017mm | 1067mm | 1092mm | 1105mm | 1118mm | 1128mm | 1152mm |
Top-Tube Length (horizontal) | 516mm | 541mm | 565mm | 586mm | 589mm | 608mm | 630mm |
Bike Stand-Over Height | 647mm | 658mm | 695mm | 732mm | 735mm | 754mm | 781mm |
Seat-Tube Length | 310mm | 310mm | 350mm | 360mm | 400mm | 400mm | 450mm |
Seat-Tube Angle | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° |
Seat-Post Length | 300mm | 300mm | 350mm | 350mm | 400mm | 400mm | 400mm |
Stem Length | 45mm | 45mm | 60mm | 60mm | 60mm | 70mm | 70mm |
